Model
|
Domain
|
SDRF
$g(x)$
|
CDF or
$F(x)$
|
PDF or
$f(x)$
|
Quantile
(m2)
|
|
Power
|
$x\in(0,\: \infty)$
$\lambda >0,\: k>0$
|
Undefined
|
$\lambda x^{k}$
|
$\lambda kx^{k-1}$
|
Undefined
|
|
Power
(shifted)
|
$x\in(a,\: \infty)$
$a\ge 0,\: \lambda >0,\: k>0$
$z=x-a$
|
Undefined
|
$\lambda z^{k}$
|
$\lambda kz^{k-1}$
|
Undefined
|
|
Logarithmic
|
$x\in(a,\: \infty)$
$\lambda >0,\: k>0$
|
Undefined
|
$k\ln x+\lambda$
|
$\dfrac{k}{x}$
|
Undefined
|
|
Logarithmic
(shifted)
|
$x\in(a,\: \infty)$
$\lambda >0,\: k>0$
$z=x-a$
|
Undefined
|
$k\ln z+\lambda$
|
$\dfrac{k}{z}$
|
Undefined
|
|
Generalized
exponential
(shifted)
|
$x\in(a,\: \infty)$
$a\ge 0,\: \lambda >0,\: k>0$
$z=\dfrac{x-a}{\lambda}$
|
$\dfrac{k}{\lambda}\dfrac{\left(1-e^{-z}\right)^{k-1}e^{-z}}{1-\left(1-e^{-z}\right)^{k}}$
|
$\left(1-e^{-z}\right)^{k}$
|
$\dfrac{k}{\lambda}\dfrac{e^{-z}}{\left(1-e^{-z}\right)^{(1-k)}}$
|
$a-\lambda\ln\left(1-p^{1/k}\right)$
|
|
Weibull
(Shifted)
|
$x\in(a,\: \infty)$
$a\ge 0,\: \lambda >0,\: k>0$
$z=\dfrac{x-a}{\lambda}$
|
$\dfrac{k}{\lambda}z^{k-1}$
|
$1-e^{-z^{k}}$
|
$\dfrac{k}{\lambda}z^{k-1}e^{-z^{k}}$
|
$a+\lambda\left(\ln\dfrac{1}{1-p}\right)^{1/k}$
|
|
Exponential
(shifted)
|
$x\in(a,\: \infty)$
$a\ge 0,\: \lambda >0$
$z=\dfrac{x-a}{\lambda}$
|
$\dfrac{1}{\lambda}$
|
$1-e^{-z}$
|
$\dfrac{1}{\lambda}e^{-z}$
|
$a-\lambda\ln(1-p)$
|
|
Inverse
Weibull
(shifted)
|
$x\in(a,\: \infty)$
$a\ge 0,\: \lambda >0,\: k>0$
$z=\dfrac{\lambda}{x-a}$
|
$\dfrac{k}{\lambda}z^{k+1}\dfrac{e^{-z^{k}}}{1-e^{-z^{k}}}$
|
$e^{-z^{k}}$
|
$\dfrac{k}{\lambda}z^{k+1}e^{-z^{k}}$
|
$a+\dfrac{\lambda}{(-\ln p)^{1/k}}$
|
|
Inverse
exponential
(shifted)
|
$x\in(a,\: \infty)$
$a\ge 0,\: \lambda >0$
$z=\dfrac{\lambda}{x-a}$
|
$\dfrac{1}{\lambda}z^{2}\dfrac{e^{-z}}{1-e^{-z}}$
|
$e^{-z}$
|
$\dfrac{1}{\lambda}z^{2}e^{-z}$
|
$a-\dfrac{\lambda}{\ln p}$
|
|
Normal
(left-
truncated)
|
$x\in(a,\: \infty)$
$a\ge 0,\: \sigma >0$
$z=\dfrac{x-\mu}{\sigma}$
|
$\dfrac{\varphi(z)}{\sigma[1-\Phi(z)]}$
$\Phi(z)=\dfrac{1}{2}{erfc}\left(-\dfrac{z}{\sqrt{2}}\right)$
$\varphi(z)=\dfrac{1}{\sqrt{2\pi}}e^{-z^{2}/2}$
|
$\dfrac{\Phi(z)-\alpha}{1-\alpha}$, $\alpha =\Phi\left(z_{a}\right)$
$z_{a}=\dfrac{a-\mu}{\sigma}$
|
$\dfrac{\varphi(z)}{(1-\alpha)\sigma}$
|
$\mu +\sigma\Phi^{-1}[\alpha +(1-\alpha)p]$
|
|
Lognormal
(shifted)
|
$x\in(a,\: \infty)$
$a\ge 0,\: \sigma >0$
$z=x-a$
|
$\dfrac{\sqrt{2/\pi}e^{-\dfrac{1}{2}\left(\dfrac{\ln z-\mu}{\sigma}\right)^{2}}}{{erfc}\left(\dfrac{\ln{z}-\mu}{\sqrt{2}\sigma}\right)\sigma{z}}$
|
$\Phi(z)=\dfrac{1}{2}{erfc}\left(-\dfrac{\ln{z}-\mu}{\sqrt{2}\sigma}\right)$
|
$\dfrac{1}{\sqrt{2\pi}\sigma z}e^{-\dfrac{1}{2}\left(\dfrac{\ln z-\mu}{\sigma}\right)^{2}}$
|
$a+\Phi^{-1}(p)$
|
|
Logistic
(left-
truncated)
|
$x\in(a,\: \infty)$
$a\ge 0,\: s>0$
$z=\dfrac{x-\mu}{s}$
|
$\dfrac{1}{s\left(1+e^{-z}\right)}$
|
$\dfrac{\Phi(z)-\alpha}{1-\alpha}$, $\alpha =\Phi\left(z_{a}\right)$
$\Phi(z)=\dfrac{1}{1+e^{-z}}$, $z_{a}=\dfrac{a-\mu}{s}$
|
$\dfrac{\varphi(z)}{(1-\alpha)s}$
$\varphi(z)=\dfrac{e^{-z}}{\left(1+e^{-z}\right)^{2}}$
|
$\mu +s\ln\dfrac{\alpha /(1-\alpha)+p}{1-p}$
|
|
Generalized
logistic
power
(shifted)
|
$x\in(a,\: \infty)$
$a\ge 0,\: \lambda >0,\: k>0,\: \beta >0$
$z=x-a$
|
$\dfrac{\beta\lambda kz^{\beta k-1}}{\left(\lambda +z^{k}\right)\left[\left(\lambda
+z^{k}\right)^{\beta}-z^{\beta k}\right]}$
|
$\left(1-\dfrac{\lambda}{\lambda +z^{k}}\right)^{\beta}$
|
$\dfrac{\beta\lambda kz^{\beta k-1}}{\left(\lambda +z^{k}\right)^{\beta +1}}$
|
$a+\left(\dfrac{\lambda p^{1/\beta}}{1-p^{1/\beta}}\right)^{1/k}$
|
|
Logistic
power
(shifted)
|
$x\in(a,\: \infty)$
$a\ge 0,\: \lambda >0,\: k>0$
$z=x-a$
|
$k\dfrac{z^{k-1}}{\lambda +z^{k}}$
|
$1-\dfrac{\lambda}{\lambda +z^{k}}$
|
$\dfrac{\lambda kz^{k-1}}{\left(\lambda +z^{k}\right)^{2}}$
|
$a+\left(\dfrac{\lambda p}{1-p}\right)^{1/k}$
|
|
Monad
(shifted)
|
$x\in(a,\: \infty)$
$a\ge 0,\: \lambda >0$
$z=x-a$
|
$\dfrac{1}{\lambda +z}$
|
$\dfrac{z}{\lambda +z}$
|
$\dfrac{\lambda}{(\lambda +z)^{2}}$
|
$a+\dfrac{\lambda p}{1-p}$
|
|
Gamma
(Shifted)
|
$x\in(a,\: \infty)$
$a\ge 0,\: \lambda >0,\: k>0$
$z=\dfrac{x-a}{\lambda}$
|
$g(z)=\dfrac{z^{k-1}e^{-z}}{\lambda[\gamma(k)-\gamma(k,\: z)]}$
|
$\dfrac{\gamma(k,\: z)}{\gamma(k)}$
|
$\dfrac{1}{\lambda\gamma(k)}z^{k-1}e^{-z}$
|
$a+\lambda\gamma^{-1}[p\gamma(k)]$
|
|
Gumbel
(left-
truncated)
|
$x\in(a,\: \infty)$
$a\ge 0,\: \lambda >0$
$z=\dfrac{x-\mu}{\lambda}$
|
$\dfrac{e^{-z}}{\lambda\left[e^{e^{-z}}-1\right]}$
|
$\dfrac{\Phi(z)-\alpha}{1-\alpha}$, $\alpha =\Phi\left(z_{a}\right)$
$\Phi(z)=e^{-e^{-z}}$, $z_{a}=\dfrac{a-\mu}{\lambda}$
|
$\dfrac{\varphi(z)}{(1-\alpha)\lambda}$
$\varphi(z)=e^{-(z+e^{-z})}$
|
$\mu -\lambda\delta$
$\delta =\ln\left(\ln\dfrac{1}{\alpha +(1-\alpha)p}\right)$
|
|
Beta
(Shifted)
|
$x\in(a,\: b)$
$a\ge 0,\: \lambda >0,\: k>0$
$z=\dfrac{x-a}{b-a}$
|
$\dfrac{z^{\lambda -1}(1-z)^{k-1}}{(b-a)[B(\lambda ,\: k)-B(z;\lambda ,\: k)]}$
|
$\dfrac{B(z;\lambda ,\: k)}{B(\lambda ,\: k)}$
|
$\dfrac{z^{\lambda -1}(1-z)^{k-1}}{(b-a)B(\lambda ,\: k)}$
|
$a+(b-a)I^{-1}(p)$
|
|
Sine power
(Shifted)
|
$x\in(a,\: \lambda)$
$a\ge 0,\: \lambda >0,\: k>0$
$z=\dfrac{x-a}{\lambda}$
|
$\dfrac{\pi k}{\lambda}z^{k-1}\tan\left(\dfrac{\pi}{2}z^{k}\right)$
|
$\dfrac{1}{2}\left[1-\cos\left(\pi z^{k}\right)\right]$
|
$\dfrac{\pi k}{2\lambda}z^{k-1}\sin\left(\pi z^{k}\right)$
|
$a+\lambda\left[\dfrac{\cos^{-1}(1-2p)}{\pi}\right]^{1/k}$
|
|
Sine
(Shifted)
|
$x\in(a,\: \lambda)$
$a\ge 0,\: \lambda >0$
$z=\dfrac{x-a}{\lambda}$
|
$\dfrac{\pi}{\lambda}\tan\left(\dfrac{\pi}{2}z\right)$
|
$\dfrac{1}{2}[1-\cos(\pi z)]$
|
$\dfrac{\pi}{2\lambda}\sin(\pi z)$
|
$a+\lambda\left[\dfrac{\cos^{-1}(1-2p)}{\pi}\right]$
|
